Description
See the Difference
Our clearest sonar ever, Active Imaging™ HD delivers the highest-definition views of Lowrance® CHIRP, SideScan and DownScan Imaging™. Experience a new level of clarity and improved target separation with extremely detailed views of fish and fish-holding structure like rockpiles, standing timber, weedbeds, ditches, drop-offs and more.
Complete FishReveal Views
Get the best of CHIRP sonar and Imaging sonar on one display with FishReveal™. First introduced with DownScan Imaging™, FishReveal is now available on SideScan*, making it quicker and easier to recognize fish targets – along with picture-like images of structure on both sides of your boat.
*The FishReveal SideScan view requires an optional S3100 sonar module.
Designed for Clarity
The Active Imaging™ HD transducer not only delivers three key sonar technologies – Lowrance® CHIRP, SideScan and DownScan Imaging™ – in one convenient package, but also features a new transducer design that boosts signal clarity.
*requires S3100 sonar module and relevant transducer for Fish Reveal SideScan on HDS Pro
Active Imaging HD 3-in-1 shows users the clearest, highest resolution images of fish and structure:
•Active Imaging HD allows for supporting Lowrance users to select the desired frequency for Side and Down separately so the angler can pick the right range/resolution for the desired view.
| SideScan Frequencies | Low CHIRP Freq. : 455 kHz (445-495 kHz)
High CHIRP Freq. : 1075 kHz (1065-1115 kHz) |
| DownScan Frequencies | Low CHIRP Freq. : 700 kHz (690-740kHz)
High CHIRP Freq. : 1200 kHz (1190-1240 kHz) |
| Side/Down Independently Selectable Freq. | Yes, Independently mix-and-match side and down frequency ranges to get the picture that you want |
| Range | Max 150ft range at High Frequency
Max 300ft range at 455 (Low Frequency) |
| Compatible Displays | Direct connect to: HDS Pro Ethernet connect to via S3100: HDS Live, EliteFS |
